| Image |
|---|
| Image Sensor | 1/2.8″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.005Lux @F1.6
B/W: 0Lux with IR on |
| WDR | 120dB Super WDR |
| Shutter Time | 1/100000s~1s |
| Day/Night Mode | Day/Night/Auto/Customize/Schedule |
| IR Wave Length | 850nm/740nm |
| IR Distance | Up to 20 m (65.62 ft) |
| S/N | >55dB |
| Lens |
|---|
| Lens | 6mm/16mm |
| Mount | M12 |
| Field of View | 6mm: H52.8°/D60.4°/V29.7°
16mm: H19.4°/D22.2°/V11° |
| Video |
|---|
| Max. Image Resolution | 4MP (2688*1520) |
| Primary Stream | 60Hz/50Hz: 15fps@(2688*1520, 2304*1296, 1920*1080, 1280*720) |
| Secondary Stream | 60Hz/50Hz: 15fps@(1280*720, 704*576, 640*480) |
| Video Compression | H.265+/H.265(HEVC)/H.264+/H.264 |
| Video Bit Rate | 16Kbps~16Mbps(CBR/VBR Adjustable) |
| Privacy Masking | Up to 4 areas (Mask) |
| ROI | Up to 8 areas |
| Image Setting | Brightness/Contrast/Saturation/Sharpness |
| Web Access | WIFI/VPN/Milesight VMS |
| Interface |
|---|
| Alarm I/O | Input *1, Output *1 |
| Audio I/O | Input *1, Output *1 |
| Ethernet | 1*RJ45 10M/100M Ethernet Port |
| RS485 | 1 |
| Wireless Network |
|---|
| WLAN | 802.11n/802.11g |
| Cellular | 4G LTE
NA: LTE-FDD(B2/4/5/12/13/14/66/71)
AU: LTE-FDD(B1/2/3/4/5/7/8/28) ; LTE-TDD(B40)
JP: LTE-FDD(B1/3/8/18/19/26); LTE-TDD(B41)
EU: LTE-FDD(B1/3/7/8/20/28A); LTE-TDD(B38/40/41) |
| SIM Card | Nano SIM |
| Intelligent Analytics |
|---|
| ANPR Distance | 6mm: Up to 10m
16mm: Up to 20m |
| Coverage | Up to 2 lanes |
| Recognition Accuracy | ≥ 95% |
| Max. Vehicle Speed | Vehicles with a speed of ≤ 70 km/h (43.5 mile/h) |
| Attributes Identification | Vehicle Type, No-plate Vehicle Capture, White/Black List Management |
| Country Region Supported | More than 20 countries and regions |
| White/Black List | Up to 20,000 records inside the camera |
| System |
|---|
| GPS | Built-in High-accuracy GPS Module |
| Storage | Support microSD/SDHC/SDXC Card Local Storage, up to 1TB |
| Advanced Function | BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering,
AGC, Anti-flicker, Corridor Mode, Deblur |
| Event Trigger | Intelligent Analytics, External Input, etc. |
| Event Action | HTTP/MQTT Post, FTP Upload, SMTP Upload, SD Card Record,
External Output, etc. |
| System Compatibility | ONVIF Profile G & M & S & T, API |
| General |
|---|
| Working Temperature | Charging: -20 °C to 45 °C
Discharging: -20 °C to 60 °C |
| Working Humidity | 0~95% (Non-condensing) |
| Power Supply | DC 12V±10% |
| Power Consumption | Sleep Mode: 0.19 W
Basic: 1.72 W (ANPR + 4G Module OFF)
Max: 3.51 W (Illuminator + ANPR + 4G streaming ON)
Basic:
Up to 9 days of battery life in cloudy/rainy conditions
(Optional up to 6 batteries. 4 batteries provide 6 days of continuous use, and 6 batteries provide 9 days of continuous use). |
| Surge Protection | 4KV |
| Weather Proof | Up to IP67-rated for Weather-resistant Performance |
| Camera Dimensions | 120*120*260 mm |
| Camera Weight | 2.2kg |
| Kit Dimensions | 1048*1150*592 mm |
| Kit Weight | 30.8kg
34.6kg (With package) |
| Certification |
|---|
| EMC | CE-EMC (EN 55032,EN 55035)
FCC (PART 15B)
RCM (AS/NZS CISPR 32) |
| Safety | CE-LVD (EN IEC 62368-1)
RCM (AS/NZS 62368.1) |
| FR | CE-RED (EN 300 328,EN301489-1,EN301489-17,EN 62133)
FCC (Part 15.247)
RCM (AS/NZS 4268,AS/CA S042.1,AS/CA S042.4,AS/NZS 2772.2)
Telec (MIC Item 19 of Article 2 Paragraph 1) |
| Environment | CE-ROHS (Directive (EU) 2015/863 amending 2011/65/EU) |
| Protection | IP67
Wind Resistance: Level 12 (Hurricane-force) |
| Controller |
|---|
| Safety Features | Over-temperature, over-discharge, over-voltage and low-temperature protection of battery; overload and short circuit protection of load. |
| Interface | M12 (8-pin) * 6: Battery Connection
M12 (6-pin): Solar Panel Input
M12 (4-pin): DC Input
M12 (5-pin): Output (including RS485)
M12 (2-pin): Output |
| Power Output | 9 to 12.6 VDC, Max. 25.2 W |
| Battery |
|---|
| Battery Type | Ternary lithium battery |
| Battery Modules in Kit | Default: 4 units of B90;
Optional: 5/6 units of B90 |
| Battery Capacity (Energy Capacity) | 90 Wh
360 Wh (4 units of B90) |
| Battery Capacity (Charge Capacity) | 8400mAh
33.6 Ah (4 units of B90) |
| Rated Voltage | 10.8V |
| Maximum Charging Voltage | 12.6V |
| Rated Charging Current | 1680mA |
| Rated discharge current | 1680mA |
| Max. Charging Current | 3000mA |
| Max. Discharge Current | 3000mA |
| Internal Resistance | <150mΩ |
| Charging Time | 5H/0.2C |
| Battery Life | More than 500 cycles |
| Operating Temperature | Charge：-20~45℃
Discharge：-20~60℃ |
| Operating Humidity | 30% ~ 90% |
| Storage Temperature | 0~45℃ |
| Storage Humidity | 40% ~ 70% |
| Port Type | M12 8-core waterproof connector |
| Weight | 640g (Single cell battery)
730g (Single cell battery with packaging) |
| Dimensions | 125*48*95 mm |
